Neoscan NXL
Large-chamber X-ray laboratory instrument (micro-CT) for non-destructive three-dimensional reconstruction of the internal microstructure of objects with a spatial resolution of 5µm
NEOSCAN NXL is a high resolution X-ray microtomography system designed for accurate 3D scanning.
It incorporates a sealed, maintenance-free microfocus X-ray source with a single 5 micron spot for exceptional spatial resolution. Its large-format detector, coupled with a fibre-optic plate and high-resolution scintillator, reduces scan time while providing superior image quality. Its large chamber can accommodate samples up to 32 cm in diameter and 54 cm in length.
The precision electro-mechanical manipulator, combined with microstepping electronics, ensures accurate sample positioning to the nearest micron. The system also includes adjustable stages for different object types and internal shielding for safe use in a standard laboratory environment in compliance with safety regulations.
Key features
- Spatial resolution: 5µm (on the JIMA pattern)
- X-ray source up to 150 kV voltage and 75W power - covering a wide range of applications
- Accommodates large objects up to 320mm in diameter and 540mm in length
- Automatic Energy Filter Changer: 8 positions to adjust acquisition optimisation
